Reynaers
MasterPatio
frame installation depth: 180 mm, sash installation depth: 77 mm, maximum sash height: 3.5 m, glazing with packages: up to 62 mm, maximum sash weight: 500 kg, monorail – single-track - permanent direct glazing in the frame (glazing from the outside), duorail – two-track - standard glazing in the sash, also available in the XOVO configuration – with an all-glass corner, we lacquer in the full RAL K7 colour palette and, on request, in other colours (use powder code), possibility of using Flyscreen mosquito net. More information can be found in the technical catalog.
- frame installation depth: 180 mm
- sash installation depth: 77 mm
- maximum sash height: 3.5 m
- glazing with packages: up to 62 mm
- maximum sash weight: 500 kg
- monorail – single-track - permanent direct glazing in the frame (glazing from the outside)
- duorail – two-track - standard glazing in the sash
- also available in the XOVO configuration – with an all-glass corner
- we lacquer in the full RAL K7 colour palette and, on request, in other colours (use powder code)
- possibility of using Flyscreen mosquito net
Price on request
0,9
Uw when Ug = 0.5
2
Guiding Rails
Details
Einbautiefe des Flügels: 77 mm,
maximale Flügelhöhe: 3,5 m,
Verglasungspakete: bis zu 62 mm,
maximales Gewicht des Flügels: 500 kg,
Monorail – eine Laufbahn – Festverglasung direkt im Rahmen (Verglasung von außen),
duorail – zwei Laufbahnen – Standardverglasung im Flügel,
auch in der XOVO-Ausführung erhältlich – mit Ganzglasecke,
Wir lackieren in der kompletten RAL K7-Palette und auf Anfrage unter einem bestimmten Pulvercode,
Möglichkeit zur Verwendung des Flyscreen-Moskitonetzes.
Weitere Informationen finden Sie im technischen Katalog.
Available colours
Technical data
- Uw (Ug 0,5)
- 0.9
- Verglasung bis
- 62 mm
